NRF24L01+ SMD 1.27MM wireless transceiver module Small Size Arduino

Specification:

NRF24L01 + wireless module

2Mbit / s 1Mbit / s 250Kbit / s transfer rate options

MultiCeiver hardware to provide the 6 receiver functions at the same time

+ / - 60 ppm crystal

Only need an external inductance when match antenna

No multi-layer PCB

5V input tolerance level

No need external level converter

Improved ShockBurst and serial interface can be easily connected with a variety of low-cost MCU

No MCU with SPI Interface

20 pin 4x4mm QFN leadless package very few external components

The 2Mbit / s rate when the peak current 12.5mA received

The 2Mbit / s rate @ 0dBm output current of 11mA peak

2Mbit / s rate of only a small average current

400nA Power-down mode, power consumption

Power consumption of 32uA in standby mode

130us fast switching and wake-up time

With on-chip voltage regulator oltage regulators

In the 1.9 to 3.6V low voltage operation

Possible to reduce noise
